Digital lever cylinder AX - configurator
Delivery Time 4-5 weeks
Digital lever cylinder AX, with interchangeable, flat lever for any cabinet door, stainless steel knobs removable, integrated drill protection (attack...
read more
- Where else cheaper?
-
Ask? we would be happy to advise you!
+49 (0) 371 50 340 270
| description | Order code | Price / pc. in € | ||
|---|---|---|---|---|
|
|
Digital lever cylinder | SV-Z5.LE.19 | 0,00 |
|
-
Digital lever cylinder AX - configurator544,68 €
Product information "Digital lever cylinder AX - configurator"
The SimonsVoss - Digital lever cylinder AX offers easy installation with interchangeable levers and a locking mechanism that prevents unauthorized opening. Drill protection safeguards the electronics, Bluetooth Low Energy enables various reading options (active, passive, hybrid), and the Secure Element stores encrypted system data as part of the AX security architecture. The product is backward compatible, has a battery life of up to 10 years, ergonomic knobs, and visual and audible feedback. All products are exclusively developed and manufactured in Germany.
SimonsVoss has also prioritized high-quality materials. This makes the AX cylinder robust and durable, while maintaining very low operating costs. Today, the AX Digital Cylinder represents the latest state of the art. It also holds the future within it, as it is equipped for further advancements and possesses the technical potential for future innovations. The AX Digital Cylinder is not compatible with the MobileKey System.
- Knobs / reader knob:
- Active cylinder stainless-steel ring cap: accessory: stainless-steel knob cap
- Hybrid cylinder: plastic cap, black
- Thumbturn knob: stainless steel
- Diameter: 32 mm
- Reading methods:
- Active transponder technology 25 kHz
- Passive with MIFARE® Classic and DESFire® smart cards and tags
- Hybrid (active and passive MIFARE® Classic and DESFire®)
- Bluetooth Low Energy (BLE)
- Operating modes:
- Offline
- Virtual network
- Online (combinable)
- Battery type: CR 2450, 3 V lithium, quantity
- 2 x (standard)
- 6 x (battery knob)
- Battery life:
- Up to 12 years standby
- or 100,000 operations (standard)
- 300,000 operations (battery knob)
- Temperature range: Operation: -25°C to +65°C (according to DIN EN 15684)
- Protection classes:
- IP54 (standard)
- IP67 (option .WP)
- Signaling:
- Acoustic (buzzer)
- and/or visual (LED – green / red)
- Offline storable access events (option .ZK): up to 3,000
- Time zone groups: 100+1
- Number of media per cylinder: up to 64,000
- Number of cylinders that can be managed per transponder: 304,000
- 868 MHz radio network: Can be networked directly with integrated LockNode (retrofit possible)
- Upgradability: Firmware upgradeable via BLE
If a different lever is to be used, it must be ordered separately and replaced during installation.
