Hanwha Vision - HCB-7000A
Delivery Time - look at hints
1/3'' AHD Kamera, Tag/Nacht, 2560x1440, BLC, 12/24V, RS-485
read more
€187.66
- Where else cheaper?
-
Ask? we would be happy to advise you!
+49 (0) 371 50 340 270
Product information "Hanwha Vision - HCB-7000A"
1/3'' AHD Kamera, Tag/Nacht, 2560x1440, BLC, 12/24V, RS-485
Manufacturer number: HCB-7000A
Download manufacturer datasheet
Main features
- 1/3'' Analog HD über Koax (AHD) Kamera
- True Day/Night mit umschaltbarem IR Sperrfilter
- QHD Auflösung 2560x1440@25fps
- Lichtempfindlichkeit 0,16 Lux bei F1,2 (Farbe)
- Verzögerungsfreie Bildübertragung bis max. 500m
- Steuerung über Koaxialkabel oder RS-485
- Einfache Installation (Plug & Play)
- FBAS-Ausgang (nur für Installation)
- Duale Stromversorgung 12VDC/24VAC
- Für Innenanwendung
Spezifications
| Alarm inputs | 0 |
| Number of alarm outputs | 1 |
| Recording sensor | CMOS |
| Motion detector | Yes |
| Image resolution max. | 2560x1440 |
| Chip size | 1/3'' |
| Digital Noise Reduction (DNR) | Yes |
| Backlight compensation | Yes |
| Heating | Yes |
| Photosensitivity | 0,16 Lux bei F1,2 |
| Protection | no information |
| Series | Wisenet HD+ |
| Control Interfaces | ACP (AHD Coax Protocol),Pelco-C (Coaxitron),RS-485 |
| Power supply | 12VDC,24VAC |
| System | True Day&Night |
| Day/night switching | Switchable IR Filter (ICR) |
| Temperature Range (Operating) | -10°C ~ +55°C |
| Wide Dynamic Range (WDR) | D-WDR |
