Hanwha Vision - HCO-6020R
Delivery Time - look at hints
1/2,8'' AHD Kamera, Bullet, Tag/Nacht, 4mm, 1920x1080, Infrarot, IP66, IK10, 12VDC
read more
€208.01
- Where else cheaper?
-
Ask? we would be happy to advise you!
+49 (0) 371 50 340 270
Product information "Hanwha Vision - HCO-6020R"
1/2,8'' AHD Kamera, Bullet, Tag/Nacht, 4mm, 1920x1080, Infrarot, IP66, IK10, 12VDC
Manufacturer number: HCO-6020R
Download manufacturer datasheet
Main features
- 1/2,8'' Analog HD über Koax Bullet Kamera
- True Day/Night mit umschaltbarem IR Sperrfilter
- Multisignal: AHD/TVI/CVI/CVBS auswählbar
- Full HD Auflösung 1920x1080@25fps
- F1,6/4 mm Festbrennweite, 87,6° HFoV
- Lichtempfindlichkeit 0,17 Lux bei F1,6 (Farbe)
- Infrarotbeleuchtung, bis 30m Reichweite
- Verzögerungsfreie Bildübertragung bis max. 500m
- Steuerung über Koax: ACP, TCP, CCP, Pelco-C
- Einfache Installation (Plug & Play)
- 12VDC Stromversorgung
- Schutzklasse IP66, IK10 Vandalismusschutz
Spezifications
| Alarm inputs | 0 |
| Number of alarm outputs | 0 |
| Recording sensor | CMOS |
| Lighting | Infrared |
| Motion detector | Yes |
| Image resolution max. | 1920x1080 |
| Horizontal angle of view | 87,6° |
| Focal length | 4 mm |
| Chip size | 1/3'' |
| Digital Noise Reduction (DNR) | Yes |
| Color (Housing) | anthrazit,Pantone Cool Gray 10C |
| Backlight compensation | Yes |
| Housing type | Outside |
| Housing material | Plastic |
| Heating | Yes |
| Photosensitivity | 0,17 Lux bei F1,6 |
| Low Speed Shutter | Yes |
| Mounting type | Ceiling,Wall |
| Lens Type | Prime lens |
| Protection | IP66 |
| Series | Wisenet HD+ |
| Control Interfaces | ACP (AHD Coax Protocol),TCP (TVI Coax Protocol),CCP (CVI Coax Protocol),Pelco-C (Coaxitron) |
| Power supply | 12VDC |
| System | True Day&Night |
| Day/night switching | Switchable IR Filter (ICR) |
| Temperature Range (Operating) | -30°C ~ +55°C |
| Wide Dynamic Range (WDR) | WDR 120dB |
