Hanwha Vision - TNM-C4960TD
Delivery Time - look at hints
Bi-Spektrum KI-Wärmebildkamera, VGA 25mm, 8M Motorized 10,9-29mm, IP66/IP67, IK10, NEMA4X
read more
€12,378.98
- Where else cheaper?
-
Ask? we would be happy to advise you!
+49 (0) 371 50 340 270
Product information "Hanwha Vision - TNM-C4960TD"
Bi-Spektrum KI-Wärmebildkamera, VGA 25mm, 8M Motorized 10,9-29mm, IP66/IP67, IK10, NEMA4X
Manufacturer number: TNM-C4960TD
Download manufacturer datasheet
Main features
- Bi-Spektrum: VGA-Wärmebild- & 8MP-Sensor sichtbar
- Maximal 30 fps bei allen Auflösungen (H.265/H.264)
- Objektiv thermisch: 25 mm feste Brennweite
- Objektiv sichtbar: 10,9-29 mm motorisiertes Varioobjektiv
- Tag & Nacht (ICR), WDR (max. 120 dB)
- Rauschunterdr.WiseNR II basierend auf KI-Engine nur sichtbar
- Smart-Codec: WiseStream III basierend auf KI-Engine sichtbar
- WiseStream II (thermisch)
- Videoanalyse basierend auf KI (sichtbar)
- IP66/IP67, NEMA4X
- PoE+ (IEEE802.3at), 12 VDC Gleichspannung
- Wand- und Mastmontage in einem Design
Spezifications
| Alarm inputs | 0 |
| Audio support | Yes |
| Image resolution max. | 3840x2160 |
| Image transfer rate max. | 30 fps |
| Vertical angle of view | [-8,+8] |
| Focal length | 25 mm,10,9 - 29 mm |
| Digital Noise Reduction (DNR) | Yes |
| Color (Housing) | weiß |
| Housing type | Outside |
| Housing material | Aluminium |
| Internal memory | microSD card slot |
| Camera Type | Bi-Spectral |
| Power consumption | 24 W |
| Mounting type | Wall,Mast mounting |
| Lens Type | Prime lens,Varifocal (motorized) |
| ONVIF | ONVIF Profile S,ONVIF Profile T |
| Protection | IP66/67 |
| Series | Wisenet T |
| Control Interfaces | Ethernet |
| Power supply | 12VDC |
| System | Thermal image,True Day&Night |
| Temperature Range (Operating) | -40°C ~ +60°C |
| Thermal resolution | 640x480 |
| Vandalism-resistant | Yes |
| Video Compression | H.265,H.264,MJPEG |
| Certifications | IK10 |
Product availability information:
The item is ordered especially for you, so it is not possible for return, withdrawal or cancellation. The following is non-binding and subject to storage and delivery information from our suppliers:
In stock: 0, Expectation: 0, Replacement time: 10 days (Last update: 04.12.2025) - subject to prior sale
