Hanwha Vision - TNO-C3012TRA
Delivery Time - look at hints
Wärmebild Netzwerk Kamera, 4,4mm, 90°, 384x288, 8fps, H.265, IP66, IK10, PoE
read more
€6,387.33
- Where else cheaper?
-
Ask? we would be happy to advise you!
+49 (0) 371 50 340 270
Product information "Hanwha Vision - TNO-C3012TRA"
Wärmebild Netzwerk Kamera, 4,4mm, 90°, 384x288, 8fps, H.265, IP66, IK10, PoE
Manufacturer number: TNO-C3012TRA
Download manufacturer datasheet
Main features
- Netzwerk-Wärmebildkamera für den Außenbereich
- Kompaktes Bullet-Style-Gehäuse
- Auflösung 384x288 Pixel mit 8 Bilder/Sek.
- Brennweite 4,4 mm: 90° HFoV
- Hochleistungsdetektor verwendet (17µm, NETD 30mK)
- AI-basierte Objektklassifizierung (Person, Fahrzeug)
- Temperaturüberwachungsbereich -40°~ 550°C
- Audio und Alarm Unterstützung
- Motion Detektion, Alarm Handover
- Schutzklasse IP66, NEMA4X, IK10
- Stromversorgung: PoE, 12V DC
Spezifications
| Alarm inputs | 0 |
| Audio support | Yes |
| Image resolution max. | 768x576 |
| Image transfer rate max. | 8 fps |
| Vertical angle of view | [-8,+8] |
| Focal length | 4,4 mm |
| Digital Noise Reduction (DNR) | Yes |
| Color (Housing) | weiß |
| Housing type | Outside |
| Housing material | Aluminium |
| Heating | Yes |
| Internal memory | microSD card slot |
| Power consumption | 11 W |
| Mounting type | Wall,Ceiling |
| Lens Type | Prime lens |
| ONVIF | ONVIF Profile S,ONVIF Profile G,ONVIF Profile T,ONVIF Profile M |
| Protection | IP66 |
| Series | Wisenet T |
| Control Interfaces | Ethernet,RS-485 |
| Power supply | 12VDC |
| System | Thermal image |
| Temperature Range (Operating) | -40°C ~ +60°C |
| Thermal resolution | 384x288 |
| Vandalism-resistant | Yes |
| Video Compression | H.265,H.264,M-JPEG |
| Certifications | IK10 |
