Hanwha Vision - TNU-6324ER
Delivery Time - look at hints
Netzwerk Positioniersystem, Ex geschützt, 1920x1080, 32x Zoom, 4,44-142,6mm, IP67, IK10, Edelstahl, Wischer, 24VAC, IR-LED
read more
€31,293.43
- Where else cheaper?
-
Ask? we would be happy to advise you!
+49 (0) 371 50 340 270
Product information "Hanwha Vision - TNU-6324ER"
Netzwerk Positioniersystem, Ex geschützt, 1920x1080, 32x Zoom, 4,44-142,6mm, IP67, IK10, Edelstahl, Wischer, 24VAC, IR-LED
Manufacturer number: TNU-6324ER
Download manufacturer datasheet
Main features
- Max. Auflösung 2 MP (1920 x 1080)
- H: 64,66° (Weitwinkel) bis 2,29° (Tele)
- V: 38,08° (Weitwinkel) bis 1,30° (Tele)
- Max. 60 fps/50 fps (60 Hz/50 Hz) bei 2 MP (H.265, H.264)
- H.265, H.264, MJPEG-Codec, WiseStream II
- IR-Beleuchtung Sichtweite 200 m
- Tag und Nacht (Auto-ICR), WDR (120 dB)
- Schwenk-/Neigefunktion: 0,1°/Sek. ~40°/Sek.
- Endlosdrehung, Voreinstellung (300 Stück)
- Explosionsschutzzertifikat: IECEx, ATEX, KCs, KC, CE/UKCA
- Edelstahl 316L, integrierter Wischer
- IP67, IK10
Spezifications
| Alarm inputs | 1 |
| Recording sensor | CMOS |
| Lighting | Infrared |
| Motion detector | Yes |
| Image resolution max. | 1920x1080 |
| Image transfer rate max. | 60 fps |
| Focal length | 4,44 - 142,6 mm |
| Digital Noise Reduction (DNR) | Yes |
| Backlight compensation | Yes |
| Housing material | Stainless steel |
| Camera Type | Explosion-proof |
| Photosensitivity | 0.05 Lux Farbe (1/30sec,30IRE) " |
| Lens Type | Auto Focus Zoom |
| ONVIF | ONVIF Profile G,ONVIF Profile S,ONVIF Profile T |
| Protection | IP67 |
| Series | Wisenet T |
| Power supply | 24VAC |
| System | True Day&Night |
| Temperature Range (Operating) | -40°C~+60°C |
| Vandalism-resistant | Yes |
| Video Compression | H.264,H.265,MJPEG |
| Wide Dynamic Range (WDR) | 120dB |
| Zoomfactor (optical) | 32 |
Product availability information:
The item is ordered especially for you, so it is not possible for return, withdrawal or cancellation. The following is non-binding and subject to storage and delivery information from our suppliers:
In stock: 0, Expectation: 0, Replacement time: 10 days (Last update: 11.01.2026) - subject to prior sale
