Hanwha Vision - XNV-6085
No longer available
1/2'' Netzwerk Dome, Fix, Tag/Nacht, 4,1-16,4mm, H.265, 1920x1080, IK10, IP66/67, PoE
read more
- Where else cheaper?
-
Ask? we would be happy to advise you!
+49 (0) 371 50 340 270
Product information "Hanwha Vision - XNV-6085"
Product availability information:
The item is ordered especially for you. The following is non-binding and subject to storage and delivery information from our suppliers:
- Discontinued line
- This article is no longer available
- Last update: 26.05.2025 - subject to prior sale
Kameratechnik - Fix Domes - Hanwha Vision - XNV-6085
1/2'' Netzwerk Dome, Fix, Tag/Nacht, 4,1-16,4mm, H.265, 1920x1080, IK10, IP66/67, PoE
Manufacturer datasheet
Hauptmerkmale
- Full-HD Auflösung 1920x1080@60fps (H.264/H.265)
- Motorisiertes 4,1-16,4mm Varifokal Objektiv, DC-Iris
- 0,004 Lux (F0,94, Farbe), eXtraLUX Low Light
- H.265/H.264/MJPEG Codec mit WiseStream II
- Wide Dynamic Range (150dB), Defog, SSNRV
- True Day&Night mit umschaltbarem IR Sperrfilter
- Hallway View und Lens Distortion Correction (LDC)
- Umfangreiche Audio- und Videoanalysefunktionen
- Digitale Bildstabilisierung mit integriertem Gyrosensor
- Dual micro SDXC Slot, FBAS & USB Installationshilfe
- Stromversorgung: PoE (IEEE802.3af), 12V DC, 24VAC
- Für Außen, Aluminiumgehäuse, IP66/67, IK10
Specifications
| System | True Day&Night |
| Compression standard | H.265 H.264 M-JPEG |
| Image transmission rate max. | 60 fps |
| Wide Dynamic Range (WDR) | WDR 150dB |
| Certificates | IK10 |
| Horizontal angle of view | 100 - 26,2 ° |
| Iris control | DC |
| Audio support | yes |
| ONVIF | yes |
| Sensitivity | 0,004 Lux$ |
| Serie | WiseNet X |
| Illumination | no |
| Colour (bubble) | clear |
| Colour (housing) | ivory Pantone Cool Gray 1C |
| Low speed shutter | yes |
| Zoom factor | 4x |
| Sensor size | 1/2'' |
| Heater | yes |
| Mounting | ceiling mount wall mount |
| Digital Zoom | 24x |
| Housing | outdoor |
| Backlight compensation | BLC HLC |
| Imager | CMOS |
| Video outputs | composite (CVBS) |
| Focal length | 4,1 - 16,4 mm |
| Internal storage | |
| Housing material | aluminium |
| Protection rating | IP66 IP67 |
| Power over Ethernet | IEEE 802.3af |
| Alarm inputs | 1 |
| Digitale Rauschunterdrückung (DNR) | SSNR5 |
| Resolution standard | HD 1080p |
| Lens type | Varifocal (motorized) |
| Lichtempfindlichkeit | bei F0,94 |
| IR cut filter | switchable |
| Temperature range (operation) | -40°C ~ +55°C |
| Vandalism resistant | yes |
| Motion detector | yes |
| Supply voltage | 12VDC 24VAC PoE |
| Resolution max. | 1920x1080 |
| Manufacturers sheet | Download PDF-document |
