Hikvision - DS-2TD2617-6/QA(O-STD)
Delivery Time - look at hints
Netzwerk Bullet Kamera, Dual, Tag/Nacht, 2688x1520, Wärmebild 6,2mm, 160x120, IP66
read more
€705.43
- Where else cheaper?
-
Ask? we would be happy to advise you!
+49 (0) 371 50 340 270
Product information "Hikvision - DS-2TD2617-6/QA(O-STD)"
Netzwerk Bullet Kamera, Dual, Tag/Nacht, 2688x1520, Wärmebild 6,2mm, 160x120, IP66
Manufacturer number: 305401429
Download manufacturer datasheet
Main features
- Wärmebild Kamera der HeatPro Serie mit DeepinView
- Thermische Auflösung 160x120 Pixel
- Optische Auflösung 2688x1520 Pixel
- Gängige Analysefunktionen integriert
- Videoanalyse mit deep learning Algorithmus
- Erkennung von Zigaretten
- Bi-Spektrum Bildfusion und Bild-in-Bild möglich
- Temperaturmessung von -20 bis 150°C
- Alarm bei Temperatur Über-/Unterschreitung
Spezifications
| Alarm inputs | 2 |
| Audio support | Yes |
| Image resolution max. | 2688x1520 |
| Image transfer rate max. | 30 fps |
| Horizontal angle of view | 25,0°,39,42° |
| Vertical angle of view | [18,+8] |
| Focal length | 6,2 mm,8 mm |
| Detection range (m) | 559 m |
| Digital Noise Reduction (DNR) | Yes |
| Color (Housing) | weiß |
| Housing type | Outside |
| Housing material | no information |
| Heating | Yes |
| Internal memory | microSD card slot |
| Camera Type | Thermometry,Fire detection |
| Power consumption | 6 W |
| Mounting type | Wall,Ceiling,Corner mounting,Mast mounting |
| Lens Type | Prime lens |
| Protection | IP66 |
| Series | Hikvision Thermal |
| Control Interfaces | Ethernet,RS-485 |
| Power supply | 12VDC,Poe |
| System | Thermal image |
| Temperature Range (Operating) | -40°C ~ +65°C |
| Thermal resolution | 160x120 |
| Video Compression | H.265,H.264,M-JPEG |
