Wall reader and controller

The revolutionary design of the SALTO KS Wall Reader in combination with the SALTO KS Control Unit, allows to optimize access control to all those doors where an electronic lock cannot be fitted. For example, fences, lifts, mechanic doors, barriers and so on. The SALTO KS Control Unit allows to increase and improve the benefits, thanks to the wall reader, to all those accesses where a lock can’t be installed. It talks wirelessly with the IQ, and reporting all events that take place on the Wall Reader SALTO KS.

Wall reader main functions:

• contactless reading of the SALTO KS Tag
• optical signalling through innovative LED design. Dual colour green/red toindicate access authorisation
• available in 2 different colors: Black and White
• connection to the SALTO KS Control Unit using UTP CAT 5 cable Max100m (200m if 2 pairs are used for the red and the black cables)
• concealed fixing screws for greater security and improved aesthetics
• gang electrical standard box measures
• dimensions: 96mm x 96mm x 15.5mm (W x H x D)
• IP66 protection rating

Control unit main features:

• SALTO KS wireless version for wireless real-time control
• all communications between the SALTO KS IQ/ Repeater and theSALTO KS locking device
• wall Reader are encrypted and secure
• wireless radio frequency based on IEEE 802.15.4 at 2,4Ghz
• cover box available in 2 different colors: Black and White
• concealed fixing screws for greater security and improved aesthetics
• dimensions: 160mm x 120mm x 34mm (W x H x D)
• LED Signalization. Green: Connected to IQ; Red: Not connected to IQ
• SALTO Power Supply included. Optional: User Power Supply inputavailable
