SALTO - XS4 Neo half locking cylinder with fixed cam - Configurator

The completely newly developed electronic SALTO - electronic XS4 Neo half locking cylinder with fixed cam combines all the advantages of wireless access control. This includes low installation effort and the possibility of equipping practically all access points with intelligence where no fitting can or should be installed.

Due to its versatility, the SALTO Neo is suitable for doors made of wood, metal, plastic and glass, for server racks, gates, cupboards, electrical switches and sliding doors - worldwide: from Central Europe to Great Britain and Scandinavia to Asia and America and even Australia and New Zealand.

Thanks to state-of-the-art technologies, it enables users to access the building without a key in a variety of ways. The SALTO Neo Cylinder works seamlessly with the SALTO Virtual Network, BLUEnet wireless technology and JustIN Mobile mobile technology, and is also compatible with SALTO KS cloud access control.

Main features

• SALTO SVN and SALTO Wireless network capable.
• All communication the carrier and the electronic cylinder is encrypted and secured.
• The batteries can be replaced without cylinder removal.
• Optical signalling through light ring.
• Dual colour green/red to indicate access authorisation.
• Acoustic signal optional.
• Equipped with anti-drilling protection.

Technicals details

• Power sorce: 4 LR1 alkaline standard batteries.
• Maximum events on lock audit: 2 200 events (non-volatile memory).
• Different cam options:
  • European profiles DIN 15mm.
• Modular cylinder body assembly on standard configuration option available.
• Available with 2 different locking thumbturns (model E2) on the inside to operate the cam.
• Anti-panic function available.

Platforms

• SALTO Virtual Network (SVN) data-on-card
  • SALTO BLUEnet wireless compatible
  • JustIN Mobile: Bluetooth SMART (BLE) & NFC
• SALTO KS
  • Mobile keys Bluetooth SMART (BLE)
• SALTO Homlok

ID technologies

• MIFARE® (DESFire EV2, Plus, Ultralight C, Classic - ISO/IEC 14443)
• HID iCLASS®
• Bluetooth SMART (BLE)
• NFC.
• SALTO KS
