SAMCON - ExCam IPM2036 T08-VA2.0.K1.BOR-LL.H-005.N-P-085
Delivery Time - look at hints
Netzwerkkamera im Edelstahlgehäuse gemäß RL 2014/34/EU (ATEX) und IECEx Ausstattung, 4MP, IR-Beleuchtung, IP68, -60°C/+60°C
read more
€4,794.45
- Where else cheaper?
-
Ask? we would be happy to advise you!
+49 (0) 371 50 340 270
Product information "SAMCON - ExCam IPM2036 T08-VA2.0.K1.BOR-LL.H-005.N-P-085"
Netzwerkkamera im Edelstahlgehäuse gemäß RL 2014/34/EU (ATEX) und IECEx Ausstattung, 4MP, IR-Beleuchtung, IP68, -60°C/+60°C
Manufacturer number: 22070394
Download manufacturer datasheet
Main features
- 1/2,7'' CMOS Sensor mit 4 MP / QHD 1440p
- Tag-/Nacht Funktionalität
- Eigenbaute IR LEDs und OptimizedIR (Reichweite 2 Meter)
- Edelstahl AISI 316L
- Zertifiziert für explosionsgefährdete Bereiche nach ATEX, IECEx,INMETRO, EAC-Ex
- Schutzart IP66/68 (IEC 60529)
- PoE, IEEE 802.3af/802.3at
- Zipstrean und Videokomprimierung H.265
- Made in Germany
Spezifications
| Audio support | No |
| Resolution standard | 4 MP |
| Recording sensor | CMOS |
| Lighting | Infrared |
| Motion detector | Yes |
| Image resolution max. | 2688 x 1512 |
| Image transfer rate max. | 30 fps |
| Horizontal angle of view | 85° |
| Focal length | 3.6 mm |
| Chip size | 1/2,7'' |
| Digital Noise Reduction (DNR) | No |
| Backlight compensation | Yes |
| Housing type | Explosion-proof |
| Housing material | AISI 316L,Stainless steel |
| Heating | Yes |
| Internal memory | microSD card slot |
| Camera Type | Anti-corrosion,Explosion-proof,Stainless steel |
| Power consumption | 13 W |
| Photosensitivity | 0,18 lux bei 50 IRE |
| Low Speed Shutter | Yes |
| Mounting type | Mast mounting,Wall |
| Lens Type | Prime lens |
| ONVIF | ONVIF Profile S,ONVIF Profile T,ONVIF Profile G |
| Power over Ethernet | IEEE 802.3af |
| Protection | IP66/68 |
| Series | ExCam |
| Control Interfaces | Ethernet |
| Power supply | Poe |
| System | True Day&Night |
| Day/night switching | yes |
| Temperature Range (Operating) | -60 °C - 60 °C |
| Video Compression | Axis Zipstream,H.264,H.265,M-JPEG |
| Wide Dynamic Range (WDR) | WDR 115dB |
| Wiper | No |
| Certifications | ATEX,EACex,INMETRO,IECEx,MASC,UKEX |
