SAMCON - ExCam IPQ1715 T08-VA2.2.K1.BOR-L.N-005.N-P
Delivery Time - look at hints
Netzwerkkamera im Edelstahlgehäuse gemäß RL 2014/34/EU (ATEX) und IECEx, 1080p, 20x optischer Motor-Zoom, IP68, -40°C/+50°C
read more
€6,166.88
- Where else cheaper?
-
Ask? we would be happy to advise you!
+49 (0) 371 50 340 270
Product information "SAMCON - ExCam IPQ1715 T08-VA2.2.K1.BOR-L.N-005.N-P"
Netzwerkkamera im Edelstahlgehäuse gemäß RL 2014/34/EU (ATEX) und IECEx, 1080p, 20x optischer Motor-Zoom, IP68, -40°C/+50°C
Manufacturer number: 22070401
Download manufacturer datasheet
Main features
- 1/2,8'' CMOS Sensor mit 2 MP (1920 x 1080)
- Leistungsstarkes Motor-Zoom-Autofokus-Objektiv (21x optisch)
- Edelstahl AISI 316L
- Zertifiziert für explosionsgefährdete Bereiche nach ATEX, IECEx,INMETRO, EAC-Ex
- Lightfinder und WDR
- Schutzart IP66/68 (IEC 60529)
- Videokomprimierung H.265
- Made in Germany
Spezifications
| Audio support | No |
| Resolution standard | 2 MP |
| Recording sensor | CMOS |
| Lighting | no |
| Motion detector | Yes |
| Image resolution max. | 1920 x 1080 |
| Image transfer rate max. | 60 fps |
| Horizontal angle of view | 76° - 3,6° |
| Vertical angle of view | 42° - 2,2° |
| Focal length | 4 - 84.6 mm |
| Chip size | 1/2,8'' |
| Digital Noise Reduction (DNR) | No |
| Backlight compensation | Yes |
| Housing type | Outside |
| Housing material | AISI 316L,Stainless steel |
| Internal memory | microSD card |
| Camera Type | Anti-corrosion,Explosion-proof,Stainless steel |
| Power consumption | 13.5 W |
| Photosensitivity | 0,1 lux bei 50 IRE |
| Low Speed Shutter | Yes |
| Mounting type | Mast mounting,Wall |
| Lens Type | Varifocal (motorized) |
| ONVIF | ONVIF Profile S,ONVIF Profile T,ONVIF Profile G,ONVIF Profile M |
| Power over Ethernet | IEEE 802.3at |
| Protection | IP66/68 |
| Series | ExCam |
| Control Interfaces | Ethernet |
| Power supply | PoE+ |
| System | True Day&Night |
| Day/night switching | yes |
| Temperature Range (Operating) | -20 °C - 60 °C |
| Video Compression | H.264,H.265,Axis Zipstream,M-JPEG |
| Wide Dynamic Range (WDR) | Forensic WDR |
| Wiper | No |
| Certifications | ATEX,EACex,INMETRO,IECEx,MASC,UKEX |
| Zoomfactor (optical) | 21 |
