SAMCON - ExCam miniTube IP T08-VA1.2.K1.BOR-N.H-005.N-P
Delivery Time - look at hints
Netzwerkkamera im Edelstahlgehäuse gemäß RL 2014/34/EU (ATEX) und IECEx, 1080p, 4x optischer Zoom, IP68, -20°C/+60°C
read more
€3,697.87
- Where else cheaper?
-
Ask? we would be happy to advise you!
+49 (0) 371 50 340 270
Product information "SAMCON - ExCam miniTube IP T08-VA1.2.K1.BOR-N.H-005.N-P"
Netzwerkkamera im Edelstahlgehäuse gemäß RL 2014/34/EU (ATEX) und IECEx, 1080p, 4x optischer Zoom, IP68, -20°C/+60°C
Manufacturer number: 22070526
Download manufacturer datasheet
Main features
- 1/2,8'' CMOS Sensor mit FullHD 1920x1080p
- Motorisiertes Varifokal Objektiv mit 4x optischen Zoom
- Tag-/Nacht Funktionalität
- Edelstahl AISI 316L
- Zertifiziert für explosionsgefährdete Bereiche nach ATEX, IECEx,INMETRO, EAC-Ex
- Schutzart IP66/68 (IEC 60529)
- Multi-Streaming und Videokomprimierung H.265
- Made in Germany
Spezifications
| Audio support | No |
| Resolution standard | 2 MP |
| Recording sensor | CMOS,Sony IMX307 |
| Lighting | no |
| Motion detector | Yes |
| Image resolution max. | 1920 x 1080 |
| Image transfer rate max. | 30 fps |
| Horizontal angle of view | 80° - 32° |
| Vertical angle of view | 56° - 18° |
| Focal length | 2.7 bis 13,5 mm |
| Chip size | 1/2,8'' |
| Digital Noise Reduction (DNR) | No |
| Backlight compensation | Yes |
| Housing type | Explosion-proof |
| Housing material | AISI 316L,Stainless steel |
| Camera Type | Anti-corrosion,Stainless steel,Explosion-proof |
| Power consumption | 4.4 W |
| Photosensitivity | 0,0008 lux bei 40 IRE |
| Low Speed Shutter | Yes |
| Mounting type | Mast mounting,Wall |
| Lens Type | Varifocal (motorized) |
| ONVIF | ONVIF Profile S,ONVIF Profile T |
| Power over Ethernet | IEEE 802.3af |
| Protection | IP66/68 |
| Series | ExCam |
| Control Interfaces | Ethernet |
| Power supply | Poe |
| System | True Day&Night |
| Day/night switching | Switchable IR Filter (ICR) |
| Temperature Range (Operating) | -30 °C - 50 °C |
| Video Compression | Axis Zipstream,H.264,H.265,M-JPEG |
| Wide Dynamic Range (WDR) | 120dB |
| Wiper | No |
| Certifications | ATEX,EACex,INMETRO,IECEx,MASC,UKEX |
| Zoomfactor (optical) | 4 |
