eneo - INM-45F0036MMA
Delivery Time 5-6 weeks
Mini Netzwerk Kamera, 2880x1620, Tag/Nacht, WDR, AI, 3,6mm, 3D DNR, 12VDC, PoE
read more
- Where else cheaper?
-
Ask? we would be happy to advise you!
+49 (0) 371 50 340 270
Product information "eneo - INM-45F0036MMA"
Product availability information:
The item is ordered especially for you. The following is non-binding and subject to storage and delivery information from our suppliers:
- In stock: 0
- Expectation: 25+ in 5 weeks
- Replacement time: 15 weeks
- Last update: 28.04.2025 - subject to prior sale
Kameratechnik - Spezialkameras - Platinenkameras - eneo - INM-45F0036MMA
Mini Netzwerk Kamera, 2880x1620, Tag/Nacht, WDR, AI, 3,6mm, 3D DNR, 12VDC, PoE
Hauptmerkmale
- 1/2,7'' CMOS-Sensor, maximale Auflösung 5 MP/30fps
- AI-Analysefunktionen inklusive Objektklassifizierung
- WDR 120dB, 3D-DNR Rauschunterdrückung
- Objektiv mit Festbrennweite 3,6mm (HFoV 91°)
- Smart Codec H.265/H.264, Multi-Streaming
- Browserunabhängig (IE, Edge, Safari, Firefox, Chrome)
- Unterstützt ONVIF Profile S/G/T/M
- Mehrsprachige Menüführung (OSD)
- Unterstützt Audio
- Spannungsversorgung PoE, 12VDC
- NDAA-Konformität
Specifications
| Dimensions (HxWxD) | see drawing |
| Alarm outputs | no |
| Alarm inputs | no |
| Analysis functions | Face Detection (FD) |
| Audio | 1/1 Line input and output |
| Audio support | yes |
| Resolution standard | 5 Megapixel |
| Imager | CMOS |
| Illumination | no |
| Motion detector | yes |
| Resolution max. | 2880x1620 |
| Image transmission rate max. | 30 fps |
| Horizontal angle of view | 91° |
| Vertical angle of view | 46° |
| Iris control | no |
| Focal length | 3,6 mm |
| Sensor size | 1/2.7'' |
| Digital zoom | yes |
| Digital Noise Reduction (DNR) | yes |
| Ethernet interface | 10Base-T |
| Colour (housing) | black |
| Remote configuration | Browser |
| Backlight compensation | BLC |
| Housing | Indoor |
| Weight | 57,2g |
| Internal storage | no |
| Camera type | Modul |
| Camera type | Board Camera |
| Power consumption | 3.8W |
| Lichtempfindlichkeit | 0,004 Lux at F1,6 |
| Low speed shutter | no |
| MOD (Minimum object distance) | 2 m |
| Mounting | Einbaumodul |
| Lens type | fixed focal length |
| ONVIF | yes |
| Power over Ethernet | IEEE 802.3af |
| Series | eneo IN-Series |
| Supply voltage | 12VDC |
| System | electronic Day&Night |
| Day&Night switch | Electronic |
| Temperature range (operation) | -35°C ~ +60°C |
| Vandalism resistant | no |
| Compression standard | H.264 |
| Wide Dynamic Range (WDR) | WDR 120dB |
| Analysis functions | Human&Vehicle Detection (PD&VD) |
| Audio | 2 Way Audio |
| Ethernet interface | 100Base-TX |
| Backlight compensation | HLC |
| ONVIF | ONVIF Profile G |
| Supply voltage | PoE |
| Compression standard | H.265 |
| Analysis functions | Intrusion (PID) |
| ONVIF | ONVIF Profile S |
| Compression standard | H.264+ (Smart Stream) |
| Analysis functions | Line Crossing Detection (LCD) |
| ONVIF | ONVIF Profile T |
| Compression standard | H.265+ (Smart Stream) |
| Analysis functions | Stationary Object Detection (SOD) |
| ONVIF | ONVIF Profile M |
| Compression standard | M-JPEG |
| Analysis functions | Cross Counting (CC) |
| Analysis functions | Crowd Density Detection (CD) |
| Analysis functions | Queue Lenght Detection (QD) |
| Analysis functions | License Plate Detection (LPD) |
| Analysis functions | Rare Sound Detection (RSD) |
