eneo - MPB-72M2713M0A

Item no.: 217277
Vendor item no.: 217277

Available, delivery time: 2-3 days

1/2,8'' HD Kamera, Tag/Nacht, 1920x1080, Infrarot, WDR, 2,7-13,5mm, 12/24V, IP67
read more

Product information "eneo - MPB-72M2713M0A"

Product availability information:
The item is ordered especially for you. The following is non-binding and subject to storage and delivery information from our suppliers:

  • In stock: 50+
  • Expectation: 50 in 6 weeks
  • Replacement time: 15 weeks
  • Last update: 13.05.2024 - subject to prior sale

eneo - Analoge/HD Kameras - Bullet - MPB-72M2713M0A
1/2,8'' HD Kamera, Tag/Nacht, 1920x1080, Infrarot, WDR, 2,7-13,5mm, 12/24V, IP67
Manufacturer datasheet


Hauptmerkmale

  • 1/2,8'' 2 Megapixel SONY STARVIS CMOS-Sensor
  • Auflösung max. 1920x1080 Pixel (Full HD)
  • Separate Ausgänge für Digital und Multisignal
  • Multisignal: HD-TVI, AHD, CVI und Composite wählbar
  • Digital Signal: EX-SDI, HD-SDI wählbar
  • Motorisiertes Objektiv 2,7~13,5mm
  • Schwenkbarer IR-Sperrfilter
  • ROI (Region of Interest) WDR Modus
  • IP67, Eingebaute Heizung
  • Einfache Installation, zentrale Fixierungsschraube
  • IR-LED Beleuchtung über OSD-Menü abschaltbar



Specifications

SystemTrue Day&Night
Wide Dynamic Range (WDR)WDR 113dB
Horizontal angle of view100 - 38 °
Iris controlDC
Alarm outputsno
Sensitivity0,08 Lux, at F1.4, 40IRE
Window heateryes
Serieseneo KX-Series eneo Candid Medium
Illuminationinfrared
Colour (housing)Pantone Cool Gray 1C
Low speed shutteryes
Zoom factor4x
Sensor size1/2.8''
Mountingwall mount ceiling mount
Power consumption10.5W
Housingoutdoor
Digital zoomno
Backlight compensationBLC HLC
ImagerCMOS
Video outputsHD-TVI AHD CVI composite (CVBS) EX-SDI HD-SDI
Protection ratingIP67
Housing materialaluminium
Focal length2,8 - 12 mm
MOD (Minimum object distance)0,5 m
Alarm inputsno
Digital Noise Reduction (DNR)yes
Lens typeVarifocal (motorized)
Sensitivityat F1.4 40IRE
IR cut filterswitchable
Temperature range (operation)-30°C ~ +50°C
Vandalism resistantno
Motion detectoryes
Supply voltage12VDC 24VAC
Vertical angle of view53 - 19 °
Resolution pixels1920x1080 1280x720 720x576
Dimensions (HxWxD)100x107,8x277mm
Analysis functionsDefog
Resolution pixels1920x1080
Illumination rangeapprox. 60m
Frame rate25/30fps @ 1920x1080p
Horizontal angle of view100 - 38°
Vertical angle of view53 - 19°
Aperture range (F)F1.4
Backlight compensationBLC
Weight1.35kg
Camera typeBullet
Sensitivity0,08 Lux
Sensitivityat F1.4
Mountingwall mount
Serieseneo KX-Series
Signal formatComposite (FBAS)
Serial interfacesCoaxitron (HD Protocol)
Supply voltage12VDC
Day&Night switchICR
Video outputsHD-TVI
Resolution pixels1280x720
Frame rate50/60fps @ 1280x720p
Backlight compensationHLC
Sensitivity40IRE
Mountingceiling mount
Serieseneo COAXIZE
Signal formatHD-TVI @ 2MP
Supply voltage24VAC
Video outputsAHD
Resolution pixels720x576
Serieseneo Candid Medium
Signal formatAHD @ 2MP
Video outputsCVI
Signal formatCVI @ 2MP
Video outputscomposite (CVBS)
Signal formatEX-SDI (270 Mbps)
Video outputsEX-SDI
Signal formatHD-SDI (1.485 Gbps)
Video outputsHD-SDI
Manufacturers sheetDownload PDF-document

0 of 0 reviews

Leave a review!

Share your experiences with other customers.


Technical details

Specifications

SystemTrue Day&Night
Wide Dynamic Range (WDR)WDR 113dB
Horizontal angle of view100 - 38 °
Iris controlDC
Alarm outputsno
Sensitivity0,08 Lux, at F1.4, 40IRE
Window heateryes
Serieseneo KX-Series eneo Candid Medium
Illuminationinfrared
Colour (housing)Pantone Cool Gray 1C
Low speed shutteryes
Zoom factor4x
Sensor size1/2.8''
Mountingwall mount ceiling mount
Power consumption10.5W
Housingoutdoor
Digital zoomno
Backlight compensationBLC HLC
ImagerCMOS
Video outputsHD-TVI AHD CVI composite (CVBS) EX-SDI HD-SDI
Protection ratingIP67
Housing materialaluminium
Focal length2,8 - 12 mm
MOD (Minimum object distance)0,5 m
Alarm inputsno
Digital Noise Reduction (DNR)yes
Lens typeVarifocal (motorized)
Sensitivityat F1.4 40IRE
IR cut filterswitchable
Temperature range (operation)-30°C ~ +50°C
Vandalism resistantno
Motion detectoryes
Supply voltage12VDC 24VAC
Vertical angle of view53 - 19 °
Resolution pixels1920x1080 1280x720 720x576
Dimensions (HxWxD)100x107,8x277mm
Analysis functionsDefog
Resolution pixels1920x1080
Illumination rangeapprox. 60m
Frame rate25/30fps @ 1920x1080p
Horizontal angle of view100 - 38°
Vertical angle of view53 - 19°
Aperture range (F)F1.4
Backlight compensationBLC
Weight1.35kg
Camera typeBullet
Sensitivity0,08 Lux
Sensitivityat F1.4
Mountingwall mount
Serieseneo KX-Series
Signal formatComposite (FBAS)
Serial interfacesCoaxitron (HD Protocol)
Supply voltage12VDC
Day&Night switchICR
Video outputsHD-TVI
Resolution pixels1280x720
Frame rate50/60fps @ 1280x720p
Backlight compensationHLC
Sensitivity40IRE
Mountingceiling mount
Serieseneo COAXIZE
Signal formatHD-TVI @ 2MP
Supply voltage24VAC
Video outputsAHD
Resolution pixels720x576
Serieseneo Candid Medium
Signal formatAHD @ 2MP
Video outputsCVI
Signal formatCVI @ 2MP
Video outputscomposite (CVBS)
Signal formatEX-SDI (270 Mbps)
Video outputsEX-SDI
Signal formatHD-SDI (1.485 Gbps)
Video outputsHD-SDI
Manufacturers sheetDownload PDF-document
