eneo - MPB-72M2713M0B
Delivery Time 15-16 weeks
1/2,8'' HD Kamera, Tag/Nacht, 1920x1080, Infrarot, WDR, 2,7-13,5mm, 12VDC, IP67
read more
- Where else cheaper?
-
Ask? we would be happy to advise you!
+49 (0) 371 50 340 270
Product information "eneo - MPB-72M2713M0B"
Product availability information:
The item is ordered especially for you. The following is non-binding and subject to storage and delivery information from our suppliers:
- In stock: 0
- Expectation: 0
- Replacement time: 15 weeks
- Last update: 10.06.2025 - subject to prior sale
Kameratechnik - Analog HD-Kameras - Bullet - eneo - MPB-72M2713M0B
1/2,8'' HD Kamera, Tag/Nacht, 1920x1080, Infrarot, WDR, 2,7-13,5mm, 12VDC, IP67
Hauptmerkmale
- 1/2,8'' 2 Megapixel SONY STARVIS 2 CMOS-Sensor
- Auflösung max. 1920x1080 Pixel (Full HD)
- Hervorragende Leistung bei schwachem Licht
- Multisignal: HD-TVI, AHD, CVI und Composite wählbar
- Digital Signal: EX-SDI, HD-SDI wählbar
- Motorisiertes Objektiv 2,7~13,5mm
- Schwenkbarer IR-Sperrfilter
- ROI (Region of Interest) WDR Modus
- Integrierter Bewegungsmelder, Defog, Privat Zonen
- IP67, Eingebaute Heizung
- Einfache Installation, zentrale Fixierungsschraube
- IR-LED Beleuchtung über OSD-Menü abschaltbar
Specifications
| Dimensions (HxWxD) | 100x108x267mm |
| Alarm outputs | no |
| Alarm inputs | no |
| Analysis functions | Defog |
| Resolution pixels | 1920x1080 |
| Imager | CMOS |
| Illumination | Infrared |
| Illumination range | approx. 60m |
| Motion detector | yes |
| Frame rate | 25/30fps @ 1920x1080p |
| Horizontal angle of view | 101 - 32° |
| Vertical angle of view | 54 - 18° |
| Aperture range (F) | F1.6 |
| Iris control | DC |
| Focal length | 2,7 - 13,5 mm |
| Sensor size | 1/2.8'' |
| Digital zoom | yes |
| Digital Noise Reduction (DNR) | yes |
| Colour (housing) | Pantone Cool Gray 1C |
| Backlight compensation | BLC |
| Housing | Outdoor |
| Housing material | Aluminium |
| Weight | 1.35kg |
| Heater | no |
| Camera type | Bullet |
| Power consumption | 8,5W |
| Lichtempfindlichkeit | 0.005Lux(Day mode), 0.0005Lux(Night mode) |
| Low speed shutter | yes |
| MOD (Minimum object distance) | 0,5 m |
| Mounting | Wall mount |
| Lens type | Varifocal (motorized) |
| Protection rating | IP67 |
| Series | eneo KX-Series |
| Signal format | Composite (FBAS) |
| Serial interfaces | Coaxitron (HD Protocol) |
| Supply voltage | 12VDC |
| System | True Day&Night |
| Day&Night switch | ICR |
| Temperature range (operation) | -30°C ~ +50°C |
| Vandalism resistant | no |
| Video outputs | HD-TVI |
| Wide Dynamic Range (WDR) | Clear HDR |
| Zoom factor | 4x |
| Resolution pixels | 1280x720 |
| Frame rate | 50/60fps @ 1280x720p |
| Digital Noise Reduction (DNR) | 3D-NR |
| Backlight compensation | HLC |
| Mounting | Ceiling mount |
| Series | eneo COAXIZE |
| Signal format | HD-TVI @ 2MP |
| Temperature range (operation) | @ Humidity 20%-80% (non-condensing) |
| Video outputs | MPX |
| Wide Dynamic Range (WDR) | D-WDR |
| Resolution pixels | 720x576 |
| Series | eneo Candid Medium |
| Signal format | AHD @ 2MP |
| Video outputs | CHD |
| Wide Dynamic Range (WDR) | DOL |
| Resolution pixels | 720x480 |
| Signal format | CHD @ 2MP |
| Video outputs | composite (CVBS) |
| Wide Dynamic Range (WDR) | Inter Frame |
| Signal format | EX-SDI (270 Mbps) |
| Video outputs | EX-SDI |
| Signal format | HD-SDI (1.485 Gbps) |
| Video outputs | HD-SDI |
