eneo - MPC-52C0000M0A
Available, delivery time: 2-3 days
1/2,8'' HD Kamera, Tag/Nacht, 1920x1080, WDR, C/CS, 12/24V
read more
- Where else cheaper?
-
Ask? we would be happy to advise you!
+49 (0) 371 50 340 270
Product availability information:
The item is ordered especially for you. The following is non-binding and subject to storage and delivery information from our suppliers:
- In stock: 50+
- Expectation: 0
- Replacement time: 15 weeks
- Last update: 29.04.2024 - subject to prior sale
eneo - Analoge/HD Kameras - Boxed Type - MPC-52C0000M0A
1/2,8'' HD Kamera, Tag/Nacht, 1920x1080, WDR, C/CS, 12/24V
Manufacturer datasheet
Hauptmerkmale
- 1/2,8'' 2 Megapixel SONY STARVIS CMOS-Sensor
- Auflösung max. 1920x1080 Pixel (Full HD)
- Separate Ausgänge für Digital und Multisignal
- Multisignal: HD-TVI, AHD, CVI und Composite wählbar
- Digital Signal: EX-SDI, HD-SDI wählbar
- Schwenkbarer IR-Sperrfilter
- ROI (Region of Interest) WDR Modus
- Integrierter Bewegungsmelder, Defog, Privat Zonen
Specifications
| Power consumption | 5W |
| Housing | indoor |
| Backlight compensation | BLC HLC |
| System | True Day&Night |
| Video outputs | HD-TVI AHD CVI composite (CVBS) EX-SDI HD-SDI |
| Imager | CMOS |
| Housing material | aluminium |
| Wide Dynamic Range (WDR) | WDR 113dB |
| Iris control | DC |
| Alarm outputs | no |
| Alarm inputs | no |
| Digital Noise Reduction (DNR) | yes |
| Sensitivity | 0,08 Lux, at F1.4, 40IRE |
| Lens mount | CS/C mount |
| Series | eneo KX-Series |
| Sensitivity | at F1.4 40IRE |
| IR cut filter | switchable |
| Colour (housing) | Pantone Cool Gray 1C |
| Temperature range (operation) | -10°C ~ +50°C |
| Low speed shutter | yes |
| Motion detector | yes |
| Supply voltage | 12VDC 24VAC |
| Sensor size | 1/2.8'' |
| Resolution pixels | 1920x1080 1280x720 720x576 |
| Dimensions (HxWxD) | 72x74x89mm |
| Analysis functions | Defog |
| Resolution pixels | 1920x1080 |
| Frame rate | 25/30fps @ 1920x1080p |
| Backlight compensation | BLC |
| Weight | 290g |
| Camera type | Box |
| Sensitivity | 0,08 Lux |
| Sensitivity | at F1.4 |
| Series | eneo KX-Series |
| Signal format | Composite (FBAS) |
| Serial interfaces | Coaxitron (HD Protocol) |
| Supply voltage | 12VDC |
| Day&Night switch | ICR |
| Video outputs | HD-TVI |
| Resolution pixels | 1280x720 |
| Frame rate | 50/60fps @ 1280x720p |
| Backlight compensation | HLC |
| Sensitivity | 40IRE |
| Series | eneo COAXIZE |
| Signal format | HD-TVI @ 2MP |
| Supply voltage | 24VAC |
| Video outputs | AHD |
| Resolution pixels | 720x576 |
| Signal format | AHD @ 2MP |
| Video outputs | CVI |
| Signal format | CVI @ 2MP |
| Video outputs | composite (CVBS) |
| Signal format | EX-SDI (270 Mbps) |
| Video outputs | EX-SDI |
| Signal format | HD-SDI (1.485 Gbps) |
| Video outputs | HD-SDI |
| Manufacturers sheet | Download PDF-document |
