eneo - MPP-62A0020M0C
Delivery Time 4-5 weeks
1/2,8'' HD Analog Dome, PTZ, Tag/Nacht, 20x, 4,7-94mm, 1920x1080, WDR, IP66
read more
- Where else cheaper?
-
Ask? we would be happy to advise you!
+49 (0) 371 50 340 270
Product information "eneo - MPP-62A0020M0C"
Product availability information:
The item is ordered especially for you. The following is non-binding and subject to storage and delivery information from our suppliers:
- In stock: 0
- Expectation: 58 in 4 weeks
- Replacement time: 17 weeks
- Last update: 10.06.2025 - subject to prior sale
Kameratechnik - Analog HD-Kameras - PTZ Domes - eneo - MPP-62A0020M0C
1/2,8'' HD Analog Dome, PTZ, Tag/Nacht, 20x, 4,7-94mm, 1920x1080, WDR, IP66
Hauptmerkmale
- 1/2,8'' Sony STARVIS CMOS-Sensor
- 20x Auto Focus Zoom, 4,7~94mm / 16x Digital
- Auflösung max. 1920x1080 (Full HD)
- Separate Ausgänge für HD Signale und Composite
- Signalformate: HD-TVI, AHD wählbar, Composite
- Real time WDR (Wide Dynamic Range) 25/30fps
- Kompaktes Design für Innen- und Außenanwendung
- 3D-DNR Noise Reduktion, Auto-Kalibrierung
- Geschützte Bereiche, Defog Funktion
- Alarm Ein- und Ausgänge, 12VDC/24VAC, IK10, IP66
Specifications
| Dimensions (HxWxD) | 150x154mm |
| Alarm outputs | 2 |
| Alarm inputs | 4 |
| Analysis functions | Defog |
| Resolution pixels | 1920x1080 |
| Imager | CMOS |
| Illumination | no |
| Motion detector | yes |
| Frame rate | 25/30fps @ 1920x1080p |
| Horizontal angle of view | 55,5 - 3° |
| Vertical angle of view | 32,4 - 1,7° |
| Aperture range (F) | F1.6~F3.0 |
| Focal length | 4,7 - 94 mm |
| Sensor size | 1/2.8'' |
| Digital zoom | 16x |
| Digital Noise Reduction (DNR) | yes |
| Rotation range | 360° |
| Colour (housing) | white |
| Colour (bubble) | clear |
| Backlight compensation | BLC |
| Housing | Outdoor |
| Housing material | Aluminium |
| Speed (manual control) | 380°/Sek. |
| Preset speed | 380°/Sek. |
| Weight | 1.6 kg |
| Camera type | PTZ |
| Power consumption | 12W |
| Lichtempfindlichkeit | 0,35 Lux at F1,6, 50IRE |
| Low speed shutter | yes |
| Blower | no |
| MOD (Minimum object distance) | 1 m |
| Mounting | Wall mount |
| Lens type | auto focus zoom |
| Window heater | no |
| Protection rating | IP66 |
| Series | eneo COAXIZE |
| Signal format | Composite (FBAS) |
| Serial interfaces | RS-485 |
| Supply voltage | 12VDC |
| System | True Day&Night |
| Day&Night switch | ICR |
| Temperature range (operation) | -10°C ~ +50°C |
| Vandalism resistant | yes |
| Video outputs | AHD |
| Wide Dynamic Range (WDR) | WDR 120dB |
| Certificates | IK10 |
| Zoom factor | 20x |
| Analysis functions | DIS (digital image stabilisation) |
| Resolution pixels | 1280x720 |
| Frame rate | 50/60fps @ 1280x720p |
| Backlight compensation | HLC |
| Mounting | Ceiling mount |
| Signal format | HD-TVI @ 2MP |
| Serial interfaces | Coaxitron (HD Protocol) |
| Supply voltage | 24VAC |
| Temperature range (operation) | @ Humidity 10%-90% (non-condensing) |
| Video outputs | HD-TVI |
| Resolution pixels | 720x576 |
| Signal format | AHD @ 2MP |
| Video outputs | composite (CVBS) |
