eneo - VM-FHD12M
Available, delivery time: 2-3 days
12'' (30cm) LCD Monitor FHD, 1920x1080, LED HDMI, VGA, Composite
read more
- Where else cheaper?
-
Ask? we would be happy to advise you!
+49 (0) 371 50 340 270
Product availability information:
The item is ordered especially for you. The following is non-binding and subject to storage and delivery information from our suppliers:
- In stock: 20+
- Expectation: 0
- Replacement time: 14 weeks
- Last update: 13.05.2024 - subject to prior sale
eneo - Monitore - Displays bis 22'' - VM-FHD12M
12'' (30cm) LCD Monitor FHD, 1920x1080, LED HDMI, VGA, Composite
Manufacturer datasheet
Hauptmerkmale
- Professioneller 12'' (30cm) LCD Monitor
- Für Dauerbetrieb ausgelegt 24x7x365 (Industrie Level)
- Maximale Auflösung 1920x1080 Pixel
- LED Hintergrundbeleuchtung
- Kurze Reaktionszeit von 5ms
- Optimale Darstellung durch digitale 3D Filterung und Rauschunterdrückung
- Vielseitige Video Eingänge HDMI, VGA, Composite
- HD analog Multisignaleingang (TVI, AHD, CVI)
- Betriebsspannung: 12VDC
- Metallgehäuse inklusive Standfuß
Specifications
| Dimensions (HxWxD) | 315x326x43mm |
| Applications | 24/7 |
| Audio output | 1x 3,5mm jack |
| Audio inputs | 1 |
| Resolution pixels | 1920x1080 |
| Viewing angle horizontal | 170 |
| Viewing angle vertical | 170 |
| Screen Size (cm) | 30 |
| Screen size | 12,5 |
| Housing color | black |
| Housing material | metal |
| Weight | 2.3kg |
| Brightness typical | 250 |
| Backlighting | LED |
| Contrast ratio typical | 1000:1 |
| Loudspeaker | 2 |
| Power consumption | 10W |
| Response time typical | 5 |
| Aspect ratio | 16:9 |
| Serial interfaces | no |
| Temperature range (operation) | -30°C ~ +85°C |
| Video outputs | 1x BNC- Signal Loop |
| Video inputs (type) | VGA |
| Temperature range (operation) | @ Humidity 10%-90% (non-condensing) |
| Video inputs (type) | 2x HDMI |
| Video inputs (type) | composite (CVBS) |
| Video inputs (type) | HD-TVI |
| Video inputs (type) | AHD |
| Video inputs (type) | CVI |
| Manufacturers sheet | Download PDF-document |
