eneo - VM-SD7M
Available, delivery time: 2-3 days
7'' (17,7cm) LCD Monitor SD, 800x480, LED, HDMI, VGA, Composite
read more
- Where else cheaper?
-
Ask? we would be happy to advise you!
+49 (0) 371 50 340 270
Product availability information:
The item is ordered especially for you. The following is non-binding and subject to storage and delivery information from our suppliers:
- In stock: 10+
- Expectation: 0
- Replacement time: 14 weeks
- Last update: 13.05.2024 - subject to prior sale
eneo - Monitore - Displays bis 22'' - VM-SD7M
7'' (17,7cm) LCD Monitor SD, 800x480, LED, HDMI, VGA, Composite
Manufacturer datasheet
Hauptmerkmale
- Professioneller 7'' (17,7cm) LCD Monitor
- Für Dauerbetrieb ausgelegt 24x7x365 (Industrie Level)
- Maximale Auflösung 800x480 Pixel
- LED Hintergrundbeleuchtung
- Kurze Reaktionszeit von 5ms
- Optimale Darstellung durch digitale 3D Filterung und Rauschunterdrückung
- Vielseitige Video Eingänge HDMI, VGA, Composite
- Lautsprecher integriert
- VESA Standard 75x75mm
- Metallgehäuse inklusive Standfuß
Specifications
| Dimensions (HxWxD) | 132x192x40mm |
| Applications | Industrie |
| Audio output | 1x 3,5mm jack |
| Audio inputs | 1 |
| Resolution pixels | 800x480 |
| Viewing angle horizontal | 178 |
| Viewing angle vertical | 178 |
| Screen Size (cm) | 17,7 |
| Screen size | 7'' |
| Housing color | black |
| Housing material | metal |
| Weight | 2.0kg |
| Brightness typical | 250 |
| Backlighting | LED |
| Contrast ratio typical | 500:1 |
| Loudspeaker | 2 |
| Power consumption | 7.5W |
| Response time typical | 5 |
| Aspect ratio | 16:9 |
| Serial interfaces | no |
| Temperature range (operation) | -30°C ~ +85°C |
| Video outputs | Composite (CVBS) |
| Video inputs (type) | VGA |
| Applications | 24/7 |
| Temperature range (operation) | @ Humidity 10%-90% (non-condensing) |
| Video inputs (type) | HDMI |
| Video inputs (type) | composite (CVBS) |
| Manufacturers sheet | Download PDF-document |
